IPmux-16 Installation and Operation Manual
Chapter 3 Operation
Configuring IPmux-16
3-13
➤
To set the Authentication/Community parameters:
1. Enter 1 to set the authentication-failure trap: On or Off. Use the Spacebar to
toggle between these two settings. When this parameter is set to On, an
authentication-failure trap is generated when a system manager attempts to set
a parameter within IPmux-16 with an incorrect community value.
2. Enter 2 to name the trap community: Enter a name of up to 10 alphanumeric
characters. The entry is case-sensitive.
3. Enter 3 to name the read community: Enter a name of up to 10 alphanumeric
characters. The entry is case-sensitive.
4. Enter 4 to name the write community: Enter a name of up to 10 alphanumeric
characters. The entry is case-sensitive.
Host Configuration
Main Menu
↓
2. Configuration
↓
1. General
Configuration
↓
2. Host
Configuration
➤
To configure the Host IP:
• Type 2 ( Host Configuration) in the General Configuration menu.
The device must be configured with the HOST IP and Mask in order to
combine the IP packet (source IP Add). This Host IP is also necessary for
the inband management capability of IPmux-16.
Frames will not leave the device until IP and Mask addresses are defined.
HOST CONFIGURATION
1. Host Index
1
2. IP Address
192.168.100.1
3. IP Mask
255. 255. 255. 0
ESC. Exit
D. Delete
Select item from the menu:_
Use
Figure 3-14. User Port Configuration Menu
➤
To change the Host ID configuration:
1. Select D.
A confirmation message is displayed “Configuration would be deleted! Are
you sure? (Y/N)”.
2. Press Y.
A second confirmation message appears “Bundle connections, Default GW
and Managers IP's will be deleted (Y/N)”.
Note
