Renesas Emulator System E8 User Manual

Page 60

3. The following dialog box is displayed.

Figure 4.4 [Setting the Target System for Debugging] Dialog Box

Select the target system for debugging and click the [Next] button.

[Target system for debugging]

[Target MCU]

M32C E8 SYSTEM:

M32C

M16C E8 SYSTEM:

M16C

R8C E8 SYSTEM:

R8C/Tiny

H8 Tiny/Super Low Power E8 SYSTEM 300H:

H8/300H Tiny, H8/300H Super Low Power

H8 Tiny/Super Low Power E8 SYSTEM 300L:

H8/300 Super Low Power

4. Set the configuration file name. The configuration file saves the setting of the High-

performance Embedded Workshop except the emulator.
