Appendix A Components of the E8 Emulator
Table A.1 lists the components of the R8C E8 emulator.
Table A.1 Components of the Emulator (R0E000080KCE00)
Classi-
fication
Component Appearance Quantity Remarks
Hard-
ware E8 emulator
(Model: R0E000080KCE00)
1 R0E000080KCE00:
Depth: 65 mm,
Width: 97 mm,
Height: 21 mm,
Mass: 60.0 g
User system interface cable 1 Length: 20 cm (connector
part not included),
Mass: 20.0 g
USB cable 1 Length: 1.5 m,
Mass: 52.0 g
E8 emulator setup program, R0E000080KCE00SR,
E8 Emulator User’s Manual, R0E000080KCE00J,
R0E000080KCE00E,
E8 Emulator additional
documents, Notes on
Connecting the xxxx R0E000080KCE00JPn,
R0E000080KCE00EPn
(n = 1, 2, 3, 4, …),
Soft-
ware
E8 emulator check program
M32C evaluation compiler
M16C evaluation compiler
and
H8 evaluation compiler
1
E8SCP.EXE
M3T-NC308WA
M3T-NC30WA
(Provided with the R8C E8
emulator setup program)
and
R0C40008XSW06R
(Provided with the H8 E8
emulator setup program)
129
