9. When [Power supply is carried out. (MAX 300mA)] is not checked, the dialog box shown in
Figure 3.17 will be displayed.
Figure 3.16 Dialog Box of the Power-on Request Message
10. The dialog box for confirming the power supply status of the user system will be displayed.
Figure 3.17 [Power Supply] Dialog Box
When [Power supply is carried out. (MAX 300mA)] is checked, power will be supplied to the user
system up to 300 mA. Then select 3.3 V or 5.0 V according to the power voltage of the user
system.
CAUTION
Before carrying out the power supply, check the power
specification of the user system and there is no short circuit
in the user system. Incorrect operation will damage the user
system and the emulator product. The USER PROGRAM will
be LOST.
31
