Roland V-Synth GT - Manual (Page 205)

205
System Mode (Settings Common to All Modes)
fig.08-14.eps_50
D-Beam
Parameter Value Description
Beam Sens L, R
(D Beam Sensitivity L, R) 0–200 This sets the D Beam Controller’s sensitivity.
Sens L is the left side, and Sens R is the right side. In-
creasing this value will make the D Beam controller
more sensitive.
Normally you will leave this at “100.”
1–4 Assign L, R
(D Beam 1–4 Assign L, R)
Specifies the MIDI controller num-
ber that will be transmitted by
movements in the D Beam Control-
ler. Assign L is the left side, and
Assign R is the right side.
OFF No message will be transmitted.
CC01–31, 33–95 Controller numbers 1–31, 33–95
