M3028BT-EPB User’s Manual 4. Hardware Specifications
REJ10J1459-0200 Rev.2.00 Sep 16, 2006
4.4.2 External Dimensions of the Converter Board M30263T-42SSB
Figure 4.3 shows external dimensions and a sample foot pattern of the converter board M30263T-42SSB (included with the
M3028BT-EPB-1) for a 42-pin 0.8mm pitch SSOP.
35.0
32
.0
6.
5
Unit: mm
0.40 +0.1
0
0.80
± 0.05
0.80
± 0.05
0.20
± 0.05
16.00
± 0.1
Max
9.
0
Mi
n1
4.
5 0.28
Figure 4.3 External dimensions and a sample foot pattern of the converter board M30263T-42SSB
4.4.3 External Dimensions of the Converter Board M30260T-48FPD
Figure 4.4 shows external dimensions and a sample foot pattern of the converter board M30260T-48FPD (included with the
M3028BT-EPB-2) for a 48-pin 0.5mm pitch LQFP.
34.0
16
.5
32
.0
0.25
0.5
7.0
10.0
7.0 10
.0
Unit: mm
Figure 4.4 External dimensions and a sample foot pattern of the converter board M30260T-48FPD
Page 70 of 86
