Page 71
M3028BT-EPB User’s Manual
4. Hardware Specifications
REJ10J1459-0200 Rev.2.00 Sep 16, 2006
4.4 External Dimensions
4.4.1 External Dimensions of the Emulation Probe
Figure 4.2 shows external dimensions of the M3028BT-EPB connected with the M30290T-PTCB.
85.0
10.0
60
.0
26
.3
Unit: mm
Figure 4.2 External dimensions of the emulation probe
Page 69 of 86
