M3028BT-EPB User’s Manual 1. Outline
REJ10J1459-0200 Rev.2.00 Sep 16, 2006
1.4 Specifications
Tables 1.5 lists the specifications of the M3028BT-EPB.
Table 1.5 M3028BT-EPB specifications (1/2)
Emulator PC7501
Applicable MCU
M16C/Tiny Series MCUs
Evaluation MCU M30290FCWP
ROM: 128KB + 4KB, RAM: 12KB
Usable MCU mode Single-chip mode
Max. ROM/RAM capacity (1) Internal flash ROM: 128KB + 4KB
0F000h--0FFFFh, E0000h--FFFFFh, for the maximum operating frequency,
refer to *1.
(2) Internal RAM: 12KB
00400h--033FFh, for the maximum operating frequency, refer to *1.
Maximum operating frequency Power voltage at 4.2 to 5.5V: 24MHz (PLL oscillation at 24MHz products)
Power voltage at 3.0 to 5.5V: 20MHz
Power voltage at 2.7 to 5.5V: 10MHz
Clock oscillator X
IN
-X
OUT
:
Internal oscillator circuit board
Switchable to external oscillator input or internal generator circuit
X
CIN
-X
COUT
(32.768kHz):
Internal oscillator circuit
Switchable to external oscillator input
Operating frequency 2.7 to 5.5 V
Power supply to emulator Supplied from DC power supply of the emulator main unit
Connection to user system For 42-pin 0.8mm pitch SSOP (PRSP0042GA-B, previous code: 42P2R-E):
M30263T-42SSB (included with the M3028BT-EPB-1) (see 2.9 "Connecting the User
System" on page 30)
For 48-pin 0.5mm pitch LQFP (PLQP0048KB-A, previous code: 48P6Q-A):
M30260T-48FPD (included with the M3028BT-EPB-2)
For 64-pin 0.5mm pitch LQFP (PLQP0064KB-A, previous code: 64P6Q-A):
M30291T-64FPD (included with the M3028BT-EPB-3)
For 80-pin 0.5mm pitch LQFP (PLQP0080KB-A, previous code: 80P6Q-A):
M30290T-80FPD (included with the M3028BT-EPB-4)
For 85-pin 0.65mm pitch TFLGA (PTLG0085JB-A, previous code: 85F0G):
M30280T-85LGF (included with the M3028BT-EPB-5)
*1 If “Disable Internal Flash ROM” of the MCU tab in the MCU Setting dialog box is checked, 0 wait access to the MCU
internal flash ROM and MCU internal RAM in the MCU is enabled at 10MHz or less.
