M3028BT-EPB User’s Manual 3. Usage (Emulator Debugger)
REJ10J1459-0200 Rev.2.00 Sep 16, 2006
2. Option
3. MCU Status
Setting the debug options
Specify whether you want to use the internal flash ROM or
the MCU or not.
Check the box when not downloading the program to the
internal flash ROM of the MCU. Initially, this option is
deselected. If this box is checked, the number of write/erase
cycles of the internal flash ROM will be unlimited, and
working efficiency (downloading, software break, etc.) will
be improved because the program is downloaded in the
emulation memory in the PC7501. However, maximum
operating frequency is 10MHz.
Referring to the MCU Status
It shows the pin status of the user system.
If the status of any pin is marked “NC”, it means that the pin
status is indeterminate.
Page 48 of 86
