M3028BT-EPB User’s Manual

2. Setup

REJ10J1459-0200 Rev.2.00 Sep 16, 2006

2.4 Connecting the PC7501

Figure 2.3 shows how to connect the PC7501 and the emulation probe.

M3T-FLX160-EPB

Emulation probe

Figure 2.3 Connecting the PC7501 and emulation probe

CAUTION

Notes on Connecting the PC7501:

z

When connecting the emulation probe, be sure to hold the both sides of the emulation probe horizontally and

insert it directly.

z

Always shut OFF power before connecting the emulation probe. Otherwise, internal circuits may be damaged.

IMPORTANT

Note on Connectors of the Converter board:

z

The connectors of the emulation probe are guaranteed for only 50 insertion/removal iterations.
