M3028BT-EPB User’s Manual 3. Usage (Emulator Debugger)
REJ10J1459-0200 Rev.2.00 Sep 16, 2006
3.3 Hardware Breakpoint Setting Window
(1) Breakpoint setup dialog box
1. Opening the hardware breakpoint setup dialog box
2. Hardware Break Point Setting Window in initial state
H/W Break Points Setting Window in initial
state
Select the “Enable H/W Break” check box, and this break
function will be enabled, allowing you to set hardware
breakpoints.
Setting Break Event
Click the event line at which you want set a break event.
Hardware Break Point
Clicking this button opens the hardware breakpoint setup
dialog box.
Page 55 of 86
