65
Detailed Settings for Each Function
Assigning Functions to Pedals
(FC1/FC2 Pedal Assign)
This setting determines the function of the pedal switches (such as the
optional DP series) or expression pedals (such as the optional EV-5/7)
that are connected to the FC1 and FC2 jacks on the rear panel.
Parameter Value
Function/
Parameter Setting Changed
FC1
FC2
00: OFF No control
CC00–CC127
Controller Numbers
0–127
129:
BEND UP
The pitch will rise in the same
way as when you move the Pitch
Bend lever toward the right.
130:
BEND DOWN
The pitch will fall in the same
way as when you move the Pitch
Bend lever toward the left.
131:
AFTERTOUCH
Controls aftertouch.
132:
OCTAVE UP
Each pedal press raises the key
range in octave steps (up to 4
octaves higher).
133:
OCTAVE DOWN
Each pedal press lowers the key
range in octave steps (up to 4
octaves lower).
134:
START/STOP
The external sequencer will
start/stop.
135:
TAP TEMPO
The tempo will be modified to
the interval at which you press
the pedal.
136:
RHY PLY/STP
Starts and stops Rhythms (p. 36).
137:
SONG PLY/STP
Starts and stops the song (p. 37).
138:
SONG RESET
Returns you to the beginning of
the song.
139:
MFX SW
Turns on/off multi-effect (p. 39).
140:
MFX CTRL
Adjusts the amount of multi-
effect (p. 39).
141:
ROTARY SPEED
When using the rotary effect,
switches the rotary effect
between slow and fast.
142:
SOUND FOCUS
Adjusts the depth of the Sound
Focus effect.
Assigning Functions to the [S1] [S2] Buttons
(S1/S2 Assign)
This setting determines the function of the [S1] and [S2] buttons.
Parameter Value
Function/
Parameter Setting Changed
S1/S2
00: OFF No control
01:
COUPLE +1OCT
Playing a key will also sound
an additional note one octave
higher.
02:
COUPLE -1OCT
Playing a key will also sound an
additional note one octave lower.
03:
COUPLE +2OCT
Playing a key will also sound
an additional note two octave
higher.
04:
COUPLE -2OCT
Playing a key will also sound an
additional note two octave lower.
05:
COUPLE +5TH
Playing a key will also sound
an additional note a fifth (7
semitones) higher.
06:
COUPLE -4TH
Playing a key will also sound
an additional note a fourth (5
semitones) lower.
07:
OCTAVE UP
Each time you press the button,
the keyboard range will rise by
an octave (maximum 4 octaves).
08:
OCTAVE DOWN
Each time you press the button,
the keyboard range will lower by
an octave (maximum 4 octaves).
09:
START/STOP
The external sequencer will start/
stop.
10:
TAP TEMPO
The tempo will be modified to
the interval at which you press
the button.
11:
SONG PLY/STP
Starts and stops the song (p. 37).
12
SONG RESET
Returns you to the beginning of
the song.
13
SONG BWD
Rewinds the song.
14
SONG FWD
Fast-forwards the song.
15:
MFX SW
Turns on/off multi-effect (p. 39).
16:
ROTARY SPEED
When using the rotary
effect, switches the rotary effect
between slow and fast.
