Page 12
14
Getting Ready
Connecting the AC Adaptor
1. Make sure that the [POWER] switch is off .
2. Move the [VOLUME] slider all the way down to minimize the volume .
3. Connect the supplied Power Cord to the included AC adaptor .
Power Cord
AC Outlet
Indicator
AC Adaptor
Place the AC adaptor so the side with the indicator (see illustration) faces upwards and the side with textual information faces downwards.
The indicator will light when you plug the AC adaptor into an AC outlet.
4. Connect the included AC adaptor to the DC IN jack located on the RD-300NX’s rear panel, and plug the power cord into an AC
outlet .
932
