Command Line Interface Syntax 3-3
202-10010-01
number 1. The field is composed of a valid slot
number and a valid port number separated by a period (.).
logical slot.port This parameter denotes a logical slot number and logical port
number assigned. This is applicable in the case of a LAG. The
operator can use the logical slot number and the logical port
number to configure the LAG.
Conventions
Network address are used to define a link to a remote host, workstation or network. Network
addresses are shown using the following syntax:
Double quotation marks such as "System Name with Spaces" set off user-defined strings. If the
operator wants to use spaces as part of a name parameter, then it must be enclosed in double
quotation marks.
Entering '@' in front of any command allows the user to reference any root command from
anywhere in the tree. For example, '>config router>@show arp table' displays the ARP table
even though the command was not executed from the root level.
Command completion finishes spelling the command when enough letters of a command are typed
to uniquely identify the command word. The command may be executed by typing
(command abbreviation) or the command word may be completed by typing the or bar> (command completion).
The value 'Err' designates that the requested value was not internally accessible. This should never
happen and indicates that there is a case in the software that is not handled correctly.
The value of '-----' designates that the value is unknown.
Table 1. Network Address Syntax
Address Type Format Range
ipAddr A.B.C.D 0.0.0.0 to 255.255.255.255
(decimal)
macAddr YY:YY:YY:YY:YY:YY hexidecimal digit pairs
