3-42 Windows Setup and Operation
IMPORTANT: If BrightStor ARCserve 2000 or Backup Exec is installed, the tape will
not be recognized due to the failover of the PCI module. Thus be sure to stop the
services before starting the PCI module.
1. Start [Services] from [Administrative Tools] of [Control Panel].
2. Select a service of backup software.
3. Choose “Stop” from the “Action” menu.
4. Repeat 2 and 3 for all services of the backup software.
The PCI modules’ status LEDs changes as shown below:
[Indications of the status LEDs]
Immediately after the PCI module startup until the completion of diagnosis
LED Secondary Primary
1 BMC status LED - Green
2 PCI module status LED1 Red -
3 PCI module status LED2 Green Amber
4 DISK ACCESS LED - Amber
DISK LED Green Amber
When duplication of disks is started after the completion of PCI module diagnosis
* The status of LEDs differ depending on the method of disk duplication.
Secondary
LED Non-RDR
model
RDR
model
Primary
1 BMC status LED - - Green
2 PCI module status LED1 - - -
3 PCI module status LED2 Amber Green Amber
4 DISK ACCESS LED Amber Green Amber
DISK LED Amber Green Amber
After the completion of disk duplication and when the PCI modules are duplicated
LED Secondary Primary
1 BMC status LED - Green
2 PCI module status LED1 - -
3 PCI module status LED2 Green Green
4 DISK ACCESS LED Green or off Green or off
DISK LED Green Green
