Windows Setup and Operation 3-37
Removing dual LAN
TIPS: To set dual LAN configuration, log on as "Administrator" or a member of the group
"Administrators".
1. Display the [Intel(R)PROSet II] dialog box.
2. Start one of the start menu modes below:
Standard start menu mode
Click [Intel(R)PROSet II] in [Control Panel] from the [Start] menu.
Classic start menu mode
(1) Select [Control Panel] from [Settings] of the [Start] menu.
(2) Double-click the [Intel(R)PROSet II] icon.
3. Remove all adapters from Duplication.
Right-click the following adapters on the control tree which is located on the left side
of the [Intel(R)PROSet II] dialog box and select [Remove from Team].
- Status emb-82559 10/100 Enet Adapter
- Status emb-82544GC Copper Gigabit Adapter
- Status AA-U51500 10/100 Enet Adapter (100BASE-TX)
- Status AA-U57000 Fiber Gigabit Adapter (1000 BASE-SX)
- NEC 8490 XT Copper Gigabit Adapter (1000 BASE-T)
You will then see the dialog box on the right of this paragraph. This is because one of
two teamed adapters constituting dual configuration is removed.
Click [Yes], to remove the adapter from Team.
