Getting started, Step lcd screen display action, Table 3-4: programming steps (continued) – Northern UTA220/UTA220k User Manual
Page 33
UTA220/UTA220k
3-9
Getting Started
Note: Some LCD screen displays require different actions
depending on the telephone company’s switch type.
Setup Step 3
Insert the ISDN line into the ISDN U jack located on the rear
panel.
27
CURRENT PORT = 2
CHANGE?
Press 3.
28
P 3 : X . 2 5 T E I = D I S
CHANGE?
Press NO
29
P3: DATA TEI = DIS.
CHANGE?
Same as Step 18.
30
P3:_____________
SPID. CHANGE?
- The SPID only needs to be configured if the TEI is not disabled.
- Enter the SPID string in the same manner as the TEI. The SPID value can be up
to 20 digits in length.
31
P3:_____________
DN. CHANGE?
- The Directory Number (DN) only needs to be configured if the TEI is not disabled.
The DN is optional for AT&T 5ESS switch types.
- Enter the DN string in the same manner as the TEIs and SPIDs. Like the SPID
strings, the DN strings can be up to 20 digits in length.
32
CURRENT PORT = 3
CHANGE?
Press 4.
33
P4: X.25 TEI=DIS
CHANGE?
Press NO
34
P4: TEI = DIS.
CHANGE?
Same as Step 18.
35
P4:_____________
SPID. CHANGE?
- The SPID only needs to be configured if the TEI is not disabled.
- Enter the SPID string in the same manner as the TEI. The SPID value can be up
to 20 digits in length.
36
P4:_____________
DN. CHANGE?
- The Directory Number (DN) only needs to be configured if the TEI is not disabled.
The DN is optional for AT&T 5ESS switch types.
- Enter the DN string in the same manner as the TEIs and SPIDs. Like the SPID
strings, the DN strings can be up to 20 digits in length.
37
CURRENT PORT = 4
CHANGE?
Press HOME.
38
D-CHANNEL LAPD
OPTIONS?
Press NO.
39
D-CHANNEL PROVISION
X.25 OPTIONS?
Press NO.
40
D-CHANNEL OPTIONS?
Press NO.
41
MULTIFRAME SYNC =
__________CHANGE?
Press NO.
42
FRONT PANEL LOCK
OPTION?
Press NO.
43
SAVE SWITCH AND
GLOBL TO NONVOL?
Press YES to save the switch configuration. The display momentarily shows
"SAVING" while it is saving the options to nonvolatile memory.
44
R E S T A R T N E T W O R K
LINK?
Plug telephone cable into ISDN U jack on rear of unit, then press YES.
Table 3-4: Programming Steps (Continued)
STEP
LCD SCREEN
DISPLAY
ACTION
