Introduction
Caution: Connecting a V.35 DTE to a non-V.35 port may
damage the DTE.
Figure 1-2. Rear Panel EIA-232 Configuration
Figure 1-3. V.35 Adaptor
If the UTA220 is ordered with the additional upper ports, then
the rear panel will also contain two additional 25-pin D-type
connectors above the two lower DTE interface connectors
(Figure 1-4).
Figure 1-4. Four Port Rear Panel Configuration
