3-6 Firmware User Guide
The pop-up Protocol menu offers the type of protocols to be assigned to this range.
• First Exposed Address: Star t IP Address of the exposed host range.
• Last Exposed Address: End IP Address of the exposed host range
• Protocol: Select the Protocol of the traffic to be allowed to the host range from the pop-up menu. Options
are Any, TCP, UDP, or TCP and UDP.
• Port Start: Star t por t of the range to be allowed to the host range. The acceptable range is from 1 -
65535.
• Port End: End por t of the range to be allowed to the host range. The acceptable range is from 1 - 65535.
Add Exposed Address Range ("xposed_list_1")
First Exposed Address: 192.168.1.10
Last Exposed Address: +-------------+
+-------------+
Protocol... | TCP and UDP |
| TCP |
| UDP |
| ANY |
+-------------+
ADD EXPOSED ADDRESS RANGE CANCEL
Add Exposed Address Range ("xposed_list_1")
First Exposed Address: 192.168.1.10
Last Exposed Address: 192.168.1.12
Protocol... TCP and UDP
Port Start: 0
Port End: 0
ADD EXPOSED ADDRESS RANGE CANCEL
Return accepts * ESC cancels * Left/Right moves insertion point * Del deletes.
