Netopia 3300 User Manual
Page 22
2-6 Firmware User Guide
7.
To add a circuit, select Add Circuit and press Return. The Add Circuit screen appears.
•
Enter a name for the circuit in the Circuit Name field.
•
Toggle Circuit Enabled to Yes.
•
Enter the Vir tual Path Identifier and the Vir tual Channel Identifier in the Circuit VPI and Circuit VCI
fields, respectively.
•
The Peak Cell Rate field is editable. Netopia Firmware Version 8.7 suppor ts three ATM classes of ser-
vice for data connections: Unspecified Bit Rate (UBR), Constant Bit Rate (CBR), and Variable Bit Rate
(VBR). You can configure these classes of ser vice on a per VC basis. The default ATM class of ser vice
is UBR.
ATM Circuits Configuration
Show/Change Circuit...
Add Circuit...
Delete Circuit...
Add Circuit
Circuit Name: Circuit 2
Circuit Enabled: Yes
Circuit VPI (0-255): 0
Circuit VCI (32-65535): +-------------+
+-------------+
QoS... | UBR |
Peak Cell Rate (0 = line rate): | CBR |
| VBR |
+-------------+
Use Connection Profile... Default Profile
Use Default Profile for Circuit
ADD Circuit NOW CANCEL
