43
8. If a label is on the end of the label liner, remove it.
a. Thread the liner around the label rewinder spindle counter-clockwise,
as shown.
b. Slide the label rewind clip over the label liner end and onto the label
rewinder spindle.
c. Fold the label liner over the clip to the back of the printer. This helps
lock in the liner.
d. Press the FEED key until the label liner is taut.
Legend:
1) Label Rewinder Spindle
2) Label Rewind Clip
9. To rewind labels, set Media Handling to Continuous in the configuration
menu. The Media Handling submenu is located in the PRINTER
CONTROL Main Configuration menu. See Chapter 3 for more information
on configuring the printer.
10. Close the printer’s front door and top (and side) cover.
1
2
