4.6.1.15.3 Classes
This section defines the available classes for the LED and graphical icon indicator
types. In the following table, x is the class number, y is the identifier of the state num-
ber for that class.
4.6.1.15.4 Assignments
This section assigns a type, a class, and, in the case of the GraphicIcon type, a physical
location and size in pixels on the LCD display or in the case of the LED type, a physi-
cal LED number.
4.6.1.15.4.1 LEDs
In the following table, x is the LED number.
4.6.1.15.4.2 Graphic Icons
In the following table, x=IP_300, IP_500, IP_600 or IP_4000, y is the graphic icon
number.
Attribute
Permitted
Values
Interpretation
ind.class.x.state.y.index
positive integer
For LED type indicators, index refers to pattern
index, i.e. index x in the
GraphicIcon type indicators, index refers to anima-
tion index, i.e. index y in the
above.
Attribute
Permitted
Values
Interpretation
ind.led.x.index
This is for internal usage only and should not be changed
(this is the logical index).
ind.led.x.class
positive integer
Assigns the class (defined above) for this indicator.
ind.led.x.physNum
This maps logical index to a specific physical LED.
Attribute
Permitted
Values
Interpretation
ind.gi.x.y.index
This is for internal usage only and should not be changed
(this is the logical index).
