Assigning DSX-1 Timeslots to the Network Interface
DSX-1 timeslots are assigned by channel allocation, where you specify individual
timeslots. The DSX-1 interface must be enabled to assign DSX-1 timeslots to the
Network interface.
Value
Meaning
N
xx
The lower field represents timeslot
xx of the selected Network
interface.
Assigned
The timeslot is already assigned to something other than a DSX-1
timeslot, so it is unavailable. Assigned timeslots cannot be modified
from this screen.
Available
The timeslot is currently unassigned.
D
ss-p/yy
Timeslot
yy of DSX-1 interface p in slot ss is assigned to the
Network timeslot identified right above it (N
xx).
Timeslot assignment rules:
H
Valid Network timeslots are either labeled as Available, or contain a DSX-1
timeslot assignment
H
Valid DSX-1 timeslots are those that are unassigned, and the currently
assigned timeslot
H
Order of display is as follows:
— Available is the first selection
— Then, from lowest DSX-1 interface to the highest DSX-1 interface
— Then lowest available timeslot number to the highest available timeslot
number
For example, if the cursor is on a field with the Available value under assigned
timeslot N
xx, pressing the Spacebar causes this field’s values to cycle through all
valid DSX-1 timeslots, starting with D
ss-p/yy, assuming it is unassigned. If
D
ss-p/yy is already assigned, the next valid timeslot in the order described above
is displayed.
