Displaying System Information
7-10 9161-A2-GH30-30 April 1998
Slot Assignment information. NAM or APM physical slot assignment
information appears below the DSX-1 interface time slot fields.
The following information is available for viewing.
Physical Slot . . . Identifies the assigned card type . . .
01 to 14 (based on model) T1 NAM – T1 NAM.
Empty – The slot is empty.
02 to 05 (based on model) Sync Data – 4-port synchronous data APM.
DSX-1 – 2-port Dual DSX APM.
E&M Voice – 8-port E&M Voice APM.
FXO Voice – 8-port FXO Voice APM.
FXS Voice – 8-port FXS Voice APM.
OCU (2) – 2-port OCU-DP APM.
OCU (6) – 6-port OCU-DP APM.
Empty – The slot is empty.
Misconfig – The slot contains a misconfigured APM.
Unsupport – The slot contains an unrecognized APM.
Failed – The slot contained an APM that has been
removed or is no longer operational.
