Displaying System Information

7-15

9161-A2-GH30-30

April 1998

Example of Network Performance Statistics Screen

ОООООООООООООООООООООООО

main/status/performance/network

9162

Device Name: Node A

01/26/96 23:32

NETWORK 1 PERFORMANCE STATISTICS

Current Interval Timer ESF Error Events

Telco=124 User = 124 Telco = 15 User = 12

–––ES–– ––UAS–– ––SES–– ––BES–– ––CSS–– –LOFC–– -Status-

Time Tel Usr Tel Usr Tel Usr Tel Usr Tel Usr Tel Usr (User)

Current: 10:37 0 0 0 0 0 0 0 0 0 0 0 0 Y

Int 01: 10:35 0 0 0 0 0 0 0 0 0 0 0 0 none

Int 02: 10:20 0 0 0 0 0 0 0 0 0 0 0 0 none

Int 03: 10:05 0 0 0 0 0 0 0 0 0 0 0 0 none

Int 04: 09:50 0 0 0 0 0 0 0 0 0 0 0 0 none

Int 05: 09:35 0 0 0 0 0 0 0 0 0 0 0 0 none

Int 06: 09:20 0 0 0 0 0 0 0 0 0 0 0 0 none

Int 07: 09:05 0 0 0 0 0 0 0 0 0 0 0 0 none

Worst Interval: 24 24 14 14 14 14 09 09 18 16 44 44

Tel Tot(valid 96): 00010 00000 00000 00000 002 003

Usr Tot(valid 96): 00010 00000 00000 00000 002 003

––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––

Ctrl-a to access these functions, ESC for previous menu

MainMenu

Exit

Refresh

PgDn

PgUp

ClrStats

Line 10

Line 13

Line 16

Line 18

Example of Sync Data Performance Statistics Screen

ОООООООООООООООООООООООО

main/status/performance/port

9162

Device Name: Node A

01/26/96 23:32

SYNC DATA PORT PERFORMANCE STATISTICS

Current Interval Timer Error Events

Near=32 Far=120 Slot 03 Data Port 4 Near=3 Far=10

–––ES–– ––UAS–– ––SES–– ––BES–– ––LOFC–– -Complete-

Near Far Near Far Near Far Near Far Near Far Far

Current: 10:37 0 0 0 0 0 0 0 0 0 0 no

Int 01: 10:35 0 0 0 0 0 0 0 0 0 0 yes

Int 02: 10:20 0 0 0 0 0 0 0 0 0 0 yes

Int 03: 10:05 0 0 0 0 0 0 0 0 0 0 yes

Int 04: 09:50 0 0 0 0 0 0 0 0 0 0 yes

Int 05: 09:35 0 0 0 0 0 0 0 0 0 0 yes

Int 06: 09:20 0 0 0 0 0 0 0 0 0 0 yes

Int 07: 09:05 0 0 0 0 0 0 0 0 0 0 yes

Worst Interval: 28 09 14 18 18 18 24 24 10 10

Near Tot(valid 32): 00010 00009 00004 00000 000

Far Tot(valid 32): 00010 00009 00004 00000 000 no
