D-1

9161-A2-GH30-30

April 1998

SNMP Cross-Reference

D

This appendix provides a correlation between how a function is performed or
status is displayed on the user interface and how the same function is
accomplished using access to the SNMP database (Table D-1). SNMP objects
are displayed in bold type while values for SNMP objects are displayed in

italics.

Table D-1.

SNMP MIB to User Interface Command Cross-Reference (1 of 16)

User Interface Command

SNMP MIB Object

STATUS

main/status/system Health & Status:

Power Supply Alarm
LOS at Net/DSX-1
OOF at Net/DSX-1
AIS at Net/DSX-1
EER at Net
Yellow at Net/DSX-1
APM Card Failed
Module MisConfig
Module Unsupported
OOF (EDL)
Out of Sync, Slot

xx Group g

EER (EDL)
Loss of Signal,

ss-p

Abnormal Station Code,

ss-p

64KCC Loop OOF,

ss-p

DDS Net Failure

xxxxxx, ss-p

Loss of Loop Timing,

ss-p

Primary Clock Failed
Secondary Clock Failed
Network Com Link Down
Device Fail

Read:

devHealthAndStatus
dsx1LossOfSignal from dsx1LineStatus for interface
dsx1LossOfFrame from dsx1LineStatus for interface
dsx1RcvAIS from dsx1LineStatus for interface
dsx1OtherFailure from dsx1LineStatus for interface
dsx1RcvFarEndLOF from dsx1LineStatus for interface
devHealthAndStatus
devHealthAndStatus
devHealthAndStatus
devHealthAndStatus
devHealthAndStatus
devHealthAndStatus
devHealthAndStatus
devHealthAndStatus
devHealthAndStatus
devHealthAndStatus
devHealthAndStatus
devHealthAndStatus
devHealthAndStatus
down from ifOperStatus for the COM port interface
devHealthAndStatus

main/status/system Self-Test Results:

All Self-Test Results

Read:
devSelfTestResults
