20 Dome C3 Display
LED A status information after initial power-on
LED B status information after initial power-on
LED Status Description
Solid green Fault
Flashing green Functional link – normal operation
Flashing red Link working, unrecognized sync information
Solid yellow Receiving DDC information
Alternating red/green No cable detected
LED Status Description
Solid green Fault
Flashing green Functional system – normal operation
