Dome C3 Display

Display Specifications

Display Category

Characteristic Item

Specification

Screen

Screen size diagonal

52.8 cm (20.8 in.)

Resolution

1536 x 2048 pixels (portrait); 2048 x 1536 pixels (landscape)

Pixel pitch

0.207 mm x 0.207 mm

Pixel arrangement

Subpixel vertical stripe

Active area (mm)

423.9 (H) x 318.0 (V)

Number of colors supported

C3 Color – 16.7 million true color (8 bits/RGB); 8-bit pseudocolor (256 colors)
C3 Gray – 3061 shades of gray – programmable gamma

Refresh rate

60 Hz

Contrast ratio

600:1 (typical)

Brightness

C3 Color – 70 fL, or 235 cd/m

2

(typical)

C3 Gray – 233 fL, or 800 cd/m

2

(typical)

Pixel rise/fall time

50 ms

Viewing angle

170° (± 85°) horizontal/vertical

Interface

Digital Video In

2 DVI single-channel digital connectors

Display control - brightness/contrast

DDC2B+

Display identification

EDID read using DDC2B+

USB hub

Universal Serial Bus (USB) Rev. 1.1: 1 uplink B port; 2 downlink A ports

Monitor status

Dual stack tricolor LEDs on back panel

Input formats

Landscape orientation

2048 x 1536 (8- and 24-bit per pixel)

Portrait orientation

1536 x 2048 (8- and 24-bit per pixel) with automatic hardware rotate

VGA™/XGA

640 x 480 to 1024 x 768 pixels displayed in both landscape and portrait rotation

Screen type

AMLCD

(active-matrix liquid crystal display)

Physical

Display size (without stand)

485.78 mm x 381 mm x 101.6 mm (19.125 in. x 15 in. x 4 in.)

Display weight (without stand)

6.35 kg (14 lb.)

Mounting options

100-mm VESA mounting standard

Power requirements

Input voltage

+12 V

±10%

Power consumption

90 Watts maximum
