Power supply, Reliability, Environment – Planar C3 User Manual
Page 27: Power supply reliability environment
QUICK LINKS
GETTING STARTED
INSTALLING THE DISPLAY
APPENDIXES
17
Dome C3 Display
Power Supply
Reliability
Environment
Power Supply Category
Characteristic Item
Specification
Power input requirements
Voltage selection
Auto-ranging
Voltage
100 – 240V AC
Current
2.0 A
Frequency
50 to 60 Hz
Power output requirements
Voltage
12 V DC
±
5%
Current
10.0 A (120 W)
Physical
Size
228.6 mm x 76.2 mm x 50.8 mm (9 in x 3 in x 2 in)
Weight
1.3 kg (2.75 lb)
Characteristic item
Specification
Display plus backlight
MTBF 50,000 hours with 50% duty cycle on backlight
Backlight
MTBF 30,000 hours to 50% brightness with backlight on continuously
Characteristic item
Specification
EMI shielding
No emission of low-level radiation
Temperature
operating
10° to 40° C
storage
-10° to 60° C
Humidity
operating
20% to 80% Relative Humidity (non-condensing)
storage
5% to 90% Relative Humidity (non-condensing)
