Configuring the DSU
3-2 7612-A2-GB20-10 November 1997
Device Name
The Device Name entry appears on all ATI screens. The input on this screen is
displayed on the Identity screen. Refer to
Identity Information on page 3-3.
System Fields
The three System entry fields are alphanumeric and provide 127 characters for
each field. The System entries appear on the Identity display as shown in the
next section. The SNMP System entry fields are:
H
System Name: The general SNMP system name.
H System Location: The physical location of the SNMP-managed device.
H
System Contact: Identification information, such as contact name, phone
number, or mailing address.
Press Ctrl-a to switch to the screen function key area below the dotted line.
Select Save and press Return. When Save is complete, Command Complete
appears at the bottom of the screen.
