Technical Specifications
F-3 7612-A2-GB20-10 November 1997
Table F-2. Model 7612 DTE Port Clock Rate
In-Band Management
Line Operating Rate
In-Band Management
Channel (IMC) Rate
56 Kbps 64 Kbps (CC or LADS)
0 (IMC disabled) 56,000 bps 64,000 bps
1,600 bps 54,400 bps 62,400 bps
4,000 bps 52,000 bps 60,000 bps
8,000 bps 48,000 bps 56,000 bps
Table F-3. Model 7612 DSU LADS Connection Distances
Wire Diameter (AWG)
Data Rate
(kbps)
19 Gauge
(.0359
I or
.9122 mm)
22 Gauge
(.0253
I or
.643 mm)
24 Gauge
(.0201
I or
.511 mm)
26 Gauge
(.0159
I or
.404 mm)
56 10.84 mi
(17.45 km)
6.4 mi
(10.3 km)
4.50 mi
(7.24 km)
3.34 mi
(5.37 km)
64 10.69 mi
(17.2 km)
6.06 mi
(9.76 km)
4.47 mi
(7.2 km)
3.20 mi
(5.15 km)
