Domestic water heaters – Lochinvar COPPER-FIN 497 - 2067 User Manual
Page 49
49
7
Domestic water heaters
(continued)
OUTLET
COLD
WATER
SUPPLY
BUILDING
HOT WATER
SUPPLY
RELIEF
VALVE
LOCK-TEMP
STORAGE
TANK
DRAIN
BUILDING
RETURN
INLET
RELIEF
VALVE
MIXING
VALVE
Figure 7-1_Typical water heater piping with storage tank
Installation & Service Manual
COMMON MANIFOLD SIZE (Min.)
Models: 497 - 747
Number of Units
GPM
Diameter
(in.)
1
60
2 1/2
COMMON MANIFOLD SIZE (Min.)
Models: 987 - 2067
Number of Units
GPM
Diameter
(in.)
1
90
2 1/2
*Please note that these illustrations are meant to show system piping concept only, the installer is responsible
for all equipment and detailing required by local codes.
NOTICE
