R E M O T E O P E R A T I O N
Status Reporting
04_06
LDX-3232
31
C H A P T E R
3
r
Figure 3.3 LDX-3232 Output Off Register
0 - LASER Current Limit
8 - N/A
1 - LASER Voltage Limit
9 - LASER Output Changed to be Out of Tolerance
2 - N/A
10 - N/A
3 - LASER Power Limit (output on)
11 - N/A
4 - N/A
12 - N/A
5 - N/A
13 - N/A
6 - N/A
14 - N/A
7 - N/A
15 - N/A
7 6 5 4 3 2 1 0
7 6 5 4 3 2 1 0
15 14 13 12 11 10
8
9
10
11
12
13
14
15
9 8
Logical
OR
Turn Output Off
LASER Output Off
Register
LASER Output Off
Enable Register
LASer:ENABle:OUTOFF
LASer:ENABle:OUTOFF?
&
&
&
&
&
&
&
&
&
&
&
&
&
&
&
&
