I N T R O D U C T I O N A N D S P E C I F I C A T I O N S
Specifications
04_06 LDX-3232 7
C H A P T E R
1
Notes
1. All values relate to a one-hour warm-up period at room temperature, 25°C.
2. Based on resolution of digital-to-analog converters used in the design.
3. Over any 1-hour period, half-scale output.
4. Over any 24-hour period, half-scale output.
5. Measured electrically with a 1 ohm load at half-scale output; evaluating spectral noise density over a 150kHz bandwidth from
125kHz to 275 kHz.
6. Maximum output current transient from normal operational situations (e.g., power on-off, current on-off), as well as accidental
situations (e.g., power line plug removal).
7. Maximum output current transient resulting from a 1000 V power-line transient spike. Tested to ILX Lightwave Technical Standard
#LDX-00196.
LDX-3232
Bandwidth (3 dB)
9
High Bandwidth
Low Bandwidth
DC to 250 kHz
DC to 10 kHz DC to 250 kHz
DC to 10 kHz
Trigger Output
Type TTL TTL
Pulse Width 13 µs 13 µs
Delay 12 ms 12 ms
Measurement (Display)
Output Current Range 0 to 2000.0 mA 0 to 4000.0 mA
Output Current Resolution
10
0.1 mA 0.1 mA
Photodiode Current Range 0 to 10,000 µA 0 to 10,000 µA
Photodiode Current Resolution 1 µA 1 µA
Photodiode Current Accuracy ±4 µA ±4 µA
PD Responsivity Range
11
0.00 to 1000.00 µA/mW 0.00 to 1000.00 µA/mW
PD Responsivity Resolution 0.01 µA/mW 0.01 µA/mW
Optical Power Range 0.00 to 5000.0 mW 0.00 to 5000.0 mW
Optical Power Resolution 0.1 mW 0.1 mW
Forward Voltage Range 0.000 to 10.000 V 0.000 to 10.000 V
Forward Voltage Resolution 1 mV 1 mV
Forward Voltage Accuracy
12
±2 mV ±2 mV
General
Size (H x W x D) 4” x 8.5” x 13.4”; 102 mm x 216 mm x 340 mm
Weight ~ 20 pounds (9 kg)
Power 100/120/230-240 V~; 2/2/1A 50/60 Hz
Temperature 0°C – 40°C operating; -40°C – 70°C storage
Humidity < 90% relative humidity, non-condensing
Laser Safety Features Key switch, interlock and output delay (meets CDRH US
21 CFR 1040.10)
Display Type 5-digit, green LED
