AI232 Version 9.6x User’s Guide
Link Configuration: General Link Properties Configuration
5-19
Configuration in the AI198 Menu System
1. Access Menu 4.2.14.12.
2. For
09*Flow Control
, enter
9
to select
None
or
XonXoff
. The default is
None
.
This async link example displays
09*Flow Control
set to
XonXoff
.
Configuration in the AI232 Local Menu System
1. Access the Link Menu.
2. For
SW Flow Control
, select
None
or
XonXoff
.
This example displays
SW Flow Control
set to
XonXoff
.
Link Description
Description
This menu item defines a description for a link.
Menu Item Type
Data
Link Type Availability
Async, AsyncPPP, and ModMux
>9
Menu 4.2.14.12
01 Link Number (1-32)--------------------------------------------------------01
02*Link Type (Async, AsyncPPP, ModMux)--------------------------------- Async
03 Link Description------------------------------ Async link 1
04*Link state (Enabled, Disabled)-------------------------------------- Enabled
05+Port speed------------------------------------------------------------- 9600
06*Port Data Bits (7, 8)------------------------------------------------------8
07*Port Stop Bits (1, 2)------------------------------------------------------1
08*Port Parity (None, Odd, Even)-------------------------------------------None
09*Flow Control (None, XonXoff)-----------------------------------------XonXoff
Async Link Menu
Link to configure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Link Description . . . . . . . . . . . . . . .................. Async link 1
Link state . . . . . . . . . . . . . . . . . . . . . [Enabled] Disabled
Link Type . . . . . . . . . . . . . . . . . [Async] AsyncPPP ModMux
Port speed (in bits per second):
300 1200 2400 4800 [9600] 19.2K 38.4K 57.6K 115.2K
Autobaud
Port data bits . . . . . . . . . . . . . . . . . . . . . Seven [Eight]
Port stop bits . . . . . . . . . . . . . . . . . . . . . . . [One] Two
Port parity . . . . . . . . . . . . . . . . . . . . [None] Even Odd
SW Flow Control . . . . . . . . . . . . . . . . . . . . None [XonXoff]
