Link Configuration: RTS/DTR Lead Control Configuration
5-48
This example displays
RTS connect state
set to
FlowControl
and
RTS disconnect state
set
to
Toggle
.
RTS/DTR Control Options Menu
Link being configured . . . . . . . . . . . . . . . . . . . . . . . . . 3
DTR connect state . . . . . . . . . . . . . . . . . . . . . . . On [Off]
DTR disconnect state . . . . . . . . . . . . . . . . . On Off [Toggle]
RTS connect state . . . . . . . . . . . . . . . . On Off [FlowControl]
RTS disconnect state . . . . . . . . . . . . . . . . . On Off [Toggle]
