AI232 Version 9.6x User’s Guide
Link Configuration: General PPP Properties Configuration
5-30
General PPP Properties Configuration
The following menu items are available for PPP configuration:
z
z
z
IPCP Address Settings
Description
The IPCP address settings are configured using three menu items:
z
Local IP address
—Defines a valid local IP address for AI232.
z
Remote IP address
—Defines an IP address for the remote device.
z
Subnet mask
—Defines a subnet mask for the link.
Menu Item Type
Data
Link Type Availability
AsyncPPP and ModMux
Configuration in the AI198 Menu System
1. Do one of the following:
z
For an asynchronous PPP link, access Menu 4.2.14.12-2.2.
z
For a ModMux link, access Menu 4.2.14.12.10.
2. For
01*Network Control Protocol
, enter
1
to select
IPCP
. The default is
IPCP
.
3. For
02 Local IP Address
, enter
2,
and the IP address. Entering
0.0.0.0
specifies
that the remote device will assign the IP address for AI232. The default is
0.0.0.0
.
4. For
03 Remote IP Address
, enter
3,
and the IP address. Entering
0.0.0.0
specifies
that the remote device will assign its own IP address. The default is
0.0.0.0
.
5. For
04 Subnet Mask
, enter
4,
and the subnet mask. The default is
255.255.255.240
.
