Page 69
AI232 Version 9.6x User’s Guide
System Configuration: SNMP Configuration
4-23
Configuration in the AI198 Menu System
1. Access Menu 4.2.14.8.
2. For
02 Node name
, enter
2,
and the node name. The maximum length is 40
characters.
3. For
03 Node location
, enter
3,
and a node location description. The maximum
length is 40 characters.
The following example displays the configuration of node name
newNode
and node
location
Office B
.
AI232 Local Menu Item Configuration
1. Access the SNMP Menu located under the System Menu.
2. For
Node name
, enter the node name. The maximum length is 40 characters.
3. For
Node location
, enter a node location description. The maximum length is 40
characters.
The following example displays the configuration of node name
newNode
and node
location
Office B
.
SNMP Manager
Description
An SNMP manager is a combination of monitoring software running on a network
management station (NMS) and the actual device running the software. It collects and
acts on information from the various devices being monitored and/or controlled. The
SNMP manager also periodically polls the devices it is managing to get status
information. AI232 allows for the configuration of up to 5 SNMP managers.
Note: SNMP managers are only configurable when AI232 is in standalone mode.
They are not configurable through the AI198 menu system.
>3,Office B
Menu 4.2.14.8
01 Contact person for this node----------------------------------------John Doe
02 Node name------------------------------------------------------------newNode
03 Node location-------------------------------------------------------Office B
SNMP Menu
Contact person for this managed node . . . . . . . . . . . . ....... John Doe
Node name . . . . . . . . . . . . . . . . . . . . . . . . . . ....... newNode
Node location . . . . . . . . . . . . . . . . . . . . . . . . ...... Office B
