AI232 Version 9.6x User’s Guide
Link Configuration: Connect Options Configuration
5-9
This example displays:
z
05*Connect when DCD is on
set to
ON
z
06*Connect when characters are received
set to
OFF
z
07*Connect without DSR, DCD or received characters
set to
OFF
.
Configuration in the AI232 Local Menu System
1. Access the Async Link Menu.
2. Select
Connect Options Menu
. The Connect Options Menu appears.
3. For
Connect when DCD is on
, select
ON
or
OFF
. The default is
OFF
.
4. For
Connect when characters are received
, select
ON
or
OFF
. The default is
ON
.
5. For
Connect without DSR, DCD or received characters
, select
ON
or
OFF
. The default is
OFF
.
This example displays:
z
Connect when DCD is on
set to
On
z
Connect when characters are received
set to
Off
z
Connect without DSR, DCD or received characters
set to
Off
.
>5
Menu 4.2.14.12.11
01*Link Application (Login, Destination, Alias)---------------------------ALIAS
02 Alias--------------------------------------------------------------async.4.1
03 Call retry interval (0 - 32767 s, 0 = disabled)------------------------00030
04 Dial/Connect when DSR is on----------------------------------------------N/A
05*Connect when DCD is on--------------------------------------------------- ON
06*Connect when characters are received-------------------------------------OFF
07*Connect without DSR, DCD or received characters--------------------------OFF
Connect Options Menu
Link being configured . . . . . . . . . . . . . . . . . . . . . . . . . 1
Link Application . . . . . . . . . . . . Login Destination [AppAlias]
Link Application Alias . . . . . . ................................. async.4.1
Call Retry Interval (0 - 32767s, 0 = disable) . . . . . . . . . . . . . .. 134
Dial/Connect when DSR is on . . . . . . . . . . . . . . . . . . On [Off]
Connect when DCD is on. . . . . . . . . . . . . . . . . . . . . [On] Off
Connect when characters are received. . . . . . . . . . . . . . On [Off]
Connect without DSR, DCD or received characters . . . . . . . . On [Off]
