AI232 Version 9.6x User’s Guide
Link Configuration: General Link Properties Configuration
5-27
Configuration in the AI232 Local Menu System
1. Access the Link Menu.
2. For Port speed , select 300 , 1200 , 2400 , 4800 , 9600 , 19.2K , 38.4K , 57.6K , 115.2K , or
Autobaud . The default is 9600 .
This example displays Port speed set to 4800 .
Port Stop Bits
Description
This menu item defines the number of stop bits. A stop bit is an extra bit at the end of
an asynchronous character that helps the receiver recognize the end of the character.
Menu Item Type
Toggle
Link Type Availability
Async and AsyncPPP
Configuration in the AI198 Menu System
1. Access Menu 4.2.14.12.
2. For 07*Port Stop Bits , enter 7 to select 1 or 2 . The default is 1 .
This example displays 07*Port Stop Bits set to 2 .
Async Link Menu
Link to configure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Link Description . . . . . . . . . . . . . . ................ New Async Link
Link state . . . . . . . . . . . . . . . . . . . . . [Enabled] Disabled
Link Type . . . . . . . . . . . . . . . . . [Async] AsyncPPP ModMux
Port speed (in bits per second):
300 1200 2400 [4800] 9600 19.2K 38.4K 57.6K 115.2K
Autobaud
>7
Menu 4.2.14.12
01 Link Number (1-32)--------------------------------------------------------01
02*Link Type (Async, AsyncPPP, ModMux)--------------------------------- Async
03 Link Description------------------------------ Async link 1
04*Link state (Enabled, Disabled)-------------------------------------- Enabled
05+Port speed------------------------------------------------------------- 9600
06*Port Data Bits (7, 8)------------------------------------------------------8
07*Port Stop Bits (1, 2)------------------------------------------------------2
