Page 50
AI232 Version 9.6x User’s Guide
System Configuration: General System Properties Configuration
4-4
Configuration in the AI232 Local Menu System
1. Access the System Menu.
2. Enter a character sequence for
Destination Menu Break Sequence
. Maximum length
is 44 characters. The default is
.
The following example displays item
Destination Menu Break Sequence
set to
.
Ethernet Port Settings
Description
The Ethernet port settings are configured using two menu items:
z
10BaseT Ethernet
—Enables or disables the 10BaseT Ethernet port on the front
panel of AI232.
z
Dual Ethernet
—Enables or disables simultaneous operation of the faceplate
mounted 10BaseT Ethernet port and the IRB.
Note: When the dual Ethernet setting is enabled, the 10BaseT Ethernet setting
has no effect on AI232 operation.
Menu Item Type
Toggle for both menu items
Configuration in the AI198 Menu System
1. Access Menu 4.2.14 pg 2.
2. For
01*10 Base T Ethernet
, enter
1
to select
OFF
or
ON
. The default is
OFF
.
3. For
07*Dual Ethernet
, enter
7
to select
OFF
or
ON
. The default is
OFF
.
This example displays
01*10 Base T Ethernet
set to
ON
and
07*Dual Ethernet
set to
OFF
.
System Menu
System Prompt . . . ................................................. [232]
Destination Menu Break Sequence . . . . . . . .....................
>7
Menu 4.2.14 pg 2
01*10 Base T Ethernet------------------------------------------------------- ON
02+Radius Configuration Menu
03 Destination Menu Break Sequence-----------------------------------
04+TACACS Configuration Menu
05 TCP Outgoing Connection Timer (2-360s)-----------------------------------075
06+TID to Modem Mux Configuration Menu
07*Dual Ethernet (On, Off)--------------------------------------------------OFF
