AI232 Version 9.6x User’s Guide
Product Description: Distribution Panels
1-10
Table 1-3 Specifications for DP232-RJ45
Description Specification
Mounting Mounts to a 19-inch or 23-inch rack
I/O Ports 32 RJ-45 ports
Weight (approximately) 4.8 lb (2.16 kg)
Size Height: 2 in. (5.08 cm)
Width: 16.9 in. (42.92 cm) without mounting flanges
Depth: 3.5 in. (8.89 cm)
Pin Assignments
Cables CAB467—Connects one connector (8 ports) on the
AI232 to the distribution panel. The distribution panel
requires four cables.
CAB513—An RJ45 to DB25 null cable that connects
network elements to the individual connectors on the
distribution panel (straight through applications).
Pin 1 Pin 8
Pin Signal
1 RTS
2 DTR
3 TXD
4 DCD
5 RXD
6 GND
7 DSR
8 CTS
