AI232 Version 9.6x User’s Guide
Link Configuration: RTS/DTR Lead Control Configuration
5-46
This example displays
01*DTR connect state
set to
OFF
and
02*DTR disconnect state
set
to
TOGGLE
.
Configuration in the AI232 Local Menu System
1. Access the Async Link Menu or AsyncPPP Link Menu.
2. Select
RTS/DTR Lead Control Options Menu
. The RTS/DTR Lead Control Options
Menu appears.
3. For
DTR connect state
, select
On
or
Off
. The default is
On
.
4. For
DTR disconnect state
, select
On
,
Off
, or
Toggle
. The default is
Off
.
This example displays
DTR connect state
set to
Off
and
DTR disconnect state
set to
Toggle
.
RTS State Configuration
Description
RTS is an RS-232 signal that is sent from a transmitting terminal to a receiving
terminal to request permission to transmit. It is configured using the following menu
items:
RTS connect state
—Sets the RTS connect state to one of the following options:
z
On
—Sets RTS to on when the link is connecting or connected.
z
Off
—Sets RTS to off when the link is connecting or connected.
z
FlowControl
—Enables RTS to follow the hardware flow control convention.
>2
Menu 4.2.14.12.13
01*DTR connect state---------------------------------------------------------ON
02*DTR disconnect state (On, Off, Toggle)--------------------------------TOGGLE
RTS/DTR Control Options Menu
Link being configured . . . . . . . . . . . . . . . . . . . . . . . . . 3
DTR connect state . . . . . . . . . . . . . . . . . . . . . . . On [Off]
DTR disconnect state . . . . . . . . . . . . . . . . . On Off [Toggle]
