AI232 Version 9.6x User’s Guide
TID Multiplexing: TID Multiplexing Configuration
6-9
11. For
09 App. string
, enter:
TID:
tid
12. (optional) For
10 Called protocol
, enter
10,
and the called protocol.
13. For
11 Caller's protocol
, enter
11,=""
.
Configuration in the AI232 Local Menu System
Note: To configure aliases in the AI232 local menu system, AI232 must be in
standalone mode.
1. Log in to the AI232 Main Menu.
2. From the AI232 Main Menu, select
Alias Menu
. The Alias Summary Menu appears.
3. From the Alias Summary Menu, select
Add Alias
. The Alias Edit Menu appears.
tid
Defines the TID of the destination NE. Maximum length is 20 characters.
Alias Edit Menu
Alias Name . . . . .
Destination . . . . .......................................................
Caller's Address . . .......................................................
Called Address . . . .......................................................
Call Data . . . . . .......................................................
Caller's Protocol . .......................................................
Called Protocol . . .......................................................
Application String . .......................................................
Alternate Route . . .......................................................
Description . . . . .......................................................
Display Alias in Destination Menu . . . . . . . . . . . . . . [Yes] No
Alias Location . . . . . . . . . . . . . . . . . . . Beginning [End]
+ Alias Test Menu
Range: {255 characters}
