AI232 Version 9.6x User’s Guide
Link Configuration: Connect Options Configuration
5-6
This example displays 03 Call retry interval set to 134 .
Configuration in the AI232 Local Menu System
1. Access the Async Link Menu.
2. Select Connect Options Menu . The Connect Options Menu appears.
3. For Call Retry Interval , enter the desired interval value. The default is 0 .
This example displays Call Retry Interval set to 134 .
Connect String
Description
This menu item configures the string that is sent after a connection is established. The
following character values apply:
z sends a break signal.
z < n > represents the decimal value of an ASCII character. Valid values are 0 to 255.
z text represents the text value in the string.
z # > represents a pause control sequence. # is the number of tenths of seconds
to pause. Valid values are 1 to 20 (for 0.1 seconds to 2 seconds).
For example, string login<13> sends:
z A break signal
z Text “login”
z A carriage return
z A 1 second pause
z Another break signal.
>3,134
Menu 4.2.14.12.11
01*Link Application (Login, Destination, Alias)---------------------------ALIAS
02 Alias--------------------------------------------------------------async.4.1
03 Call retry interval (0 - 32767 s, 0 = disabled)------------------------00134
Connect Options Menu
Link being configured . . . . . . . . . . . . . . . . . . . . . . . . . 1
Link Application . . . . . . . . . . . . Login Destination [AppAlias]
Link Application Alias . . . . . . ................................. async.4.1
Call Retry Interval (0 - 32767s, 0 = disable) . . . . . . . . . . . . . .. 134
