AI232 Version 9.6x User’s Guide
Link Configuration: General Link Properties Configuration
5-23
Port Data Bits
Description
This menu item defines the number of databits in a data byte.
Menu Item Type
Toggle
Link Type Availability
Async and AsyncPPP
Configuration in the AI198 Menu System
1. Access Menu 4.2.14.12.
2. For 06*Port Data Bits , enter 6 to select 7 or 8 . The default is 8 .
This example displays 06*Port Data Bits set to 7 .
Configuration in the AI232 Local Menu System
1. Access the Async Link Menu or AsyncPPP Link Menu.
2. For Port data bits , select Seven or Eight . The default is Eight .
>6
Menu 4.2.14.12
01 Link Number (1-32)--------------------------------------------------------01
02*Link Type (Async, AsyncPPP, ModMux)--------------------------------- Async
03 Link Description------------------------------ Async link 1
04*Link state (Enabled, Disabled)-------------------------------------- Enabled
05+Port speed------------------------------------------------------------- 9600
06*Port Data Bits (7, 8)------------------------------------------------------7
