AI232 Commands: diag-line
8-54
Examples
This example displays a typical default line monitor display for asynchronous data.
06>d FF 03 00 31 00 01 FF FF FF FF FF FF 00 00 92 9B ...1............
59 0C 08 06 00 01 08 00 06 04 00 01 00 00 92 9B Y...............
59 0C AC 10 32 05 00 00 00 00 00 00 AC 10 22 79 Y...2........."y
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ................
00 00 ..
06
77 00 00 00 00 80 00 00 40 72 00 6F 77 80 04 00 [email protected]...
00 14 00 02 00 0F 00 .......
06>d FF 03 00 31 00 01 FF FF FF FF FF FF 00 10 4B D0 ...1..........K.
D3 5D 08 06 00 01 08 00 06 04 00 01 00 10 4B D0 .]............K.
D3 5D AC 10 33 D1 00 00 00 00 00 00 AC 10 20 EB .]..3......... .
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ................
00 00 ..
06>d FF 03 00 31 00 01 FF FF FF FF FF FF 00 10 4B D0 ...1..........K.
D3 5D 08 06 00 01 08 00 06 04 00 01 00 10 4B D0 .]............K.
D3 5D AC 10 33 D1 00 00 00 00 00 00 AC 10 1E 82 .]..3...........
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ................
00 00 ..
Column
Description
Line number
Displays the line number, which can range from
01
to
32
.
Direction indicator
Displays the direction indicator for the line. One of the
following appears:
z
>
for transmitted frames
z
<
for received frames.
Frame type indicator
Displays the frame type indicator for the line. One of the
following appears:
z
d
for asynchronous links
z
Blank for other frames or packets.
Data
If the data field byte count is disabled, it gets displayed as
ct: <# of bytes in data field>
. If the data display is enabled
and only present in data packets, then the data byte count is
displayed as
.
