AI232 Version 9.6x User’s Guide
TID Multiplexing: TID Multiplexing Troubleshooting
6-16
Normal Response Example
This example displays the response that appears when RTRV-HDR:AI232:12345; is
executed.
Error Response Format
If AI232 receives TL1 commands other than RTRV-HDR with the same card TID, it
responds with a deny message. This example displays the deny message format.
Table 6-2 describes each of the items in the above response format.
YY-MM-DD Specifies the date.
HH:MM:SS Specifies the time of day.
ctag Specifies the correlation tag.
COMPLD Specifies completion. The Input requirement is satisfied.
AI232 00-04-14 05:06:39
M 12345 COMPLD;
MDENY
;
Table 6-2 Error Response Format Description
Response Item Description
cr Specifies a carriage return.
lf Specifies a line feed.
sp Specifies a space.
SID Specifies a system identifier (system ID).
YY-MM-DD Specifies the date.
HH:MM:SS Specifies the time of day.
ctag Specifies the correlation tag.
DENY Specifies that the input requirement is not satisfied.
Table 6-1 RTRV-HDR Response Format Description (Continued)
Response Item Description
