Section 3. Interface Specifications
SATO CL408e/CL412e Service Manual
PN 9001078
Rev. B
The EXT connector on the rear panel of the CL408e/CL412e printers is intended for use with
external printer accessories such as label rewinders or applicators. The 14 pin Centronics type
connector provides a choice of four different output signals along with various error conditions. A
DB-9 to 14 pin Centronics adapter cable is provided for legacy applications.
