Replacing the power supply, Figs. 6-9 – SATO CL 408e User Manual

Page 110

Page 6-10

Section 6. Replacement Procedures

SATO CL408e/CL412e Service Manual

PN 9001078

Rev. B

Replacing the Power Supply

REMOVE (2)

SCREWS

POWER
SUPPLY

Figs. 6-9

REMOVE
SCREW

POWER
SUPPLY

DETACH

CONNECTORS
